VMware vSphere

VMware vSphere is the compute virtualization platform at the foundation of VMware Cloud Foundation. Organizations use it to consolidate workloads onto fewer servers, improve availability with automated failover, and run both VMs and Kubernetes on unified infrastructure.

vSphere Standard and Enterprise Plus are End of Sale (Nov 1, 2026). vSphere is now available as vSphere Express (up to 128 cores), vSphere Foundation and VMware Cloud Foundation. See migration paths ›

Best for

  • Enterprise server consolidation and workload management
  • Running VMs and Kubernetes on one platform
  • High availability and zero-downtime maintenance
  • GPU-accelerated AI/ML workloads on private cloud
VMware vSphere product icon

Enterprise Compute Virtualization for VMware Cloud Foundation

The Compute Problem vSphere Solves

What is VMware vSphere?

VMware vSphere is the enterprise compute virtualization platform in VMware Cloud Foundation. It includes the ESXi hypervisor, vCenter Server for centralized management, and capabilities like DRS, HA, vMotion, and vSphere Kubernetes Service. Organizations use vSphere to consolidate workloads, improve availability, and run both VMs and containers on one platform.

Many organizations still run one application per physical server — or manage aging virtualization environments that lack automation, Kubernetes support, and modern security. vSphere modernizes the compute layer so infrastructure teams can deliver resources faster while maintaining control.

Server sprawl icon

Server Sprawl & Underutilization

Running one application per physical server wastes hardware capacity. Most physical servers run at 10-15% utilization, driving up hardware costs, power, cooling, and data center footprint.

vSphere consolidates multiple workloads onto fewer servers. A typical vSphere deployment achieves 15-20 VMs per host, reducing hardware requirements by 80% or more.

Downtime icon

Planned & Unplanned Downtime

Physical servers require maintenance windows for patching and hardware changes. When a server fails, applications go down until the hardware is repaired.

vSphere HA automatically restarts VMs on healthy hosts after a failure. vMotion migrates running VMs between hosts with zero downtime for maintenance — no application interruption required.

Separate platforms icon

Separate VM & Container Platforms

Organizations running Kubernetes alongside traditional VMs often manage two separate infrastructure stacks — one for VMs, one for containers — with different tooling, security models, and operations teams.

vSphere Kubernetes Service (VKS) runs CNCF-certified Kubernetes directly on the hypervisor. VMs and containers share the same infrastructure, networking, and management plane.

When Organizations Choose vSphere

vSphere is the right choice when your organization needs a proven, enterprise-grade compute platform that handles both traditional and modern workloads.

Data Center Consolidation

Reduce physical server count by running multiple workloads per host. vSphere's Distributed Resource Scheduler (DRS) automatically balances load across the cluster, ensuring efficient resource utilization without manual intervention.

Typical scenario: An organization running 200 physical servers consolidates to 15 vSphere hosts, reducing hardware costs, power, and data center footprint by 80%.

Business-Critical Applications

Run production databases, ERP systems, and mission-critical applications with high availability. vSphere HA restarts VMs automatically after host failures. Fault Tolerance provides continuous availability for applications that cannot tolerate any downtime.

Typical scenario: A healthcare system runs electronic health records on vSphere with HA and vMotion, ensuring patient-facing applications remain available during both planned maintenance and unplanned failures.

Kubernetes & Modern Applications

Run containers alongside traditional VMs on the same infrastructure. vSphere Kubernetes Service provides a CNCF-certified Kubernetes distribution with enterprise security, integrated networking via NSX, and a single management plane for both workload types.

Typical scenario: A platform engineering team provides developers with Kubernetes clusters through self-service, running on the same vSphere infrastructure that hosts production VMs — no separate container platform required.

AI/ML & GPU Workloads

vSphere supports GPU passthrough, multi-instance GPU (MIG), and virtual GPU (vGPU) for running AI and machine learning workloads on private cloud infrastructure. The Distributed Services Engine offloads networking to DPUs, freeing CPU and GPU resources for application workloads.

Typical scenario: A financial services firm runs ML model training on GPU-equipped vSphere hosts, keeping sensitive data on-premises while leveraging the same infrastructure management tools used for traditional workloads.

vSphere Standard & Enterprise Plus: End of Sale and Migration Paths

Broadcom has retired the standalone vSphere Standard and vSphere Enterprise Plus editions. vSphere is now purchased as vSphere Express, vSphere Foundation (VVF) or VMware Cloud Foundation (VCF). Existing customers should plan their move before End of Service.

Milestone
vSphere Standard
vSphere Enterprise Plus
End of Sale
November 1, 2026
November 1, 2026
End of Service (vSphere 8.x)
October 11, 2027
October 11, 2027

vSphere Standard Customers

Up to 128 cores and need VDS or vSphere 9.1 features: consider vSphere Express, sold as a single 128-core pack.

Need resource management, operational visibility or advanced hardware support: move to vSphere Foundation (VVF) or VCF.

vSphere Enterprise Plus Customers

Using DRS, memory tiering, SR-IOV or GPU/vGPU: move to VVF or VCF.

Relying mainly on the Distributed Switch: vSphere Express may be a cost-appropriate fit (the 128-core cap applies).

Which one fits? vSphere Express covers environments up to 128 cores with vCenter, vMotion, HA and VDS. VVF adds DRS, memory tiering, SR-IOV, GPU/vGPU and VCF Operations. VCF adds NSX, VCF Automation and Private AI for a full private cloud. Most servers certified for vSphere 8.x are also certified for 9.x. Compare all three ›

How vSphere Fits in the VMware Cloud Foundation Stack

vSphere is the compute layer in VMware Cloud Foundation. It works alongside vSAN (storage), NSX (networking), and SDDC Manager (lifecycle management) to deliver a complete private cloud platform.

Layer
Component
Function
Compute
VMware vSphere
Hypervisor, VM management, Kubernetes runtime
Storage
Software-defined storage, encryption, deduplication
Networking
Software-defined networking, VPCs, micro-segmentation
Management
SDDC Manager
Lifecycle management and orchestration

Typical vSphere Deployment

  • vCenter Server — centralized management for all ESXi hosts, VMs, and Kubernetes clusters
  • ESXi hosts — bare-metal hypervisor installed on each physical server in the cluster
  • Clusters — groups of hosts with shared resources, HA, and DRS
  • vSphere Kubernetes Service — CNCF-certified Kubernetes running on the hypervisor layer

Key Availability Features

  • vSphere HA — automatic VM restart on healthy hosts after a failure
  • vMotion — live migration of running VMs between hosts with zero downtime
  • Storage vMotion — live migration of VM storage without interruption
  • DRS — automatic load balancing across the cluster (VVF and VCF)
  • Fault Tolerance — continuous availability with synchronized VM replicas

What vSphere Customers Are Saying

With rapid provisioning of servers through virtualization, we can now scale horizontally to handle bursts, and we've been able to successfully handle surges.

— Make-a-Wish Foundation

READ CASE STUDY

Virtualization has allowed us to expose core services across our apps in a scalable manner and completely redefine the user experience.

— Bharti Airtel Limited

READ CASE STUDY

Deploying vSphere and vSAN got rid of the legacy three-tier architecture. We adopted a hyperconverged architecture, helping us reduce TCO by 15%.

— JM Financial

READ CASE STUDY

vSphere Licensing & Buying Guidance

Subscription Licensing

vSphere is sold by subscription through authorized resellers. Broadcom no longer offers perpetual vSphere licenses, and vSphere Standard and Enterprise Plus reached End of Sale on November 1, 2026.

vSphere Express is a single 128-core pack (one per customer). VVF and VCF are per core, with a minimum order of 96 cores per Contract ID.

Express vs. VVF vs. VCF

Small environments up to 128 cores can start with vSphere Express. vSphere Foundation (VVF) includes vSphere and vSAN with DRS and VCF Operations. VMware Cloud Foundation (VCF) adds NSX networking and SDDC Manager.

Organizations building a full private cloud typically choose VCF. Those primarily focused on compute virtualization may start with Express or VVF.

Getting a Quote

Broadcom does not publish list pricing publicly. Contact our team with your environment details — number of hosts, cores per host, and workload requirements — for a sizing estimate and quote.

REQUEST A QUOTE

VMware vSphere — Buyer FAQ

No. vSphere Standard and vSphere Enterprise Plus reached End of Sale on November 1, 2026. End of Service for vSphere 8.x Standard and Enterprise Plus is October 11, 2027.

vSphere Standard customers with up to 128 cores should consider vSphere Express. Customers using DRS, memory tiering, SR-IOV or GPU/vGPU should move to vSphere Foundation (VVF) or VMware Cloud Foundation (VCF).

vSphere Foundation includes vSphere and vSAN — compute and storage. VMware Cloud Foundation adds NSX networking and SDDC Manager for lifecycle automation.

If you primarily need server virtualization with hyperconverged storage, VVF may be sufficient. If you need software-defined networking, micro-segmentation, self-service VPCs, or automated lifecycle management across the full stack, VCF is the right choice.

Yes. vSphere includes vSphere Kubernetes Service (VKS), a CNCF-certified Kubernetes distribution that runs directly on the hypervisor. VMs and containers share the same infrastructure, networking, and security model.

VKS supports cluster autoscaling (including scale-from-zero), Service Mesh integration, and FIPS Mode. It integrates with NSX for container networking and micro-segmentation.

vSphere runs on standard x86 servers from Dell, HPE, Lenovo, and other major vendors. VMware publishes a Hardware Compatibility Guide (HCL) listing validated server configurations.

For GPU workloads, vSphere supports NVIDIA GPU passthrough, vGPU, and multi-instance GPU configurations. DPU support requires compatible SmartNICs for the Distributed Services Engine.

Both vSphere and Microsoft Hyper-V are enterprise hypervisors. The key differences are in ecosystem breadth, management capabilities, and advanced features.

vSphere provides more mature live migration (vMotion), automated load balancing (DRS), and integrated Kubernetes support. It also has a larger ecosystem of third-party integrations for backup, monitoring, and security. Organizations with existing VMware skills and tooling typically stay with vSphere for operational consistency.

VMware vSphere Resources

Talk to a VMware Virtualization Architect

VirtualizationWorks is an authorized VMware reseller. Our team helps organizations move off vSphere Standard and Enterprise Plus, choose between vSphere Express, VVF and VCF, size deployments, and plan migrations from legacy infrastructure.

Contact Us
